汇分7855型纯水烟雾发生器是经济实用的一款纯水喷雾器，烟雾发生器利用超声波雾化的原理, 将纯水用超声波雾化成1—10 微米左右的大量水雾,在外部压力的作用下, 通过发烟管排出，可以呈现出较浓的烟雾，在多个行业特别是洁净室行业中测试气流组织状态是十分直观的。
主要参数
电压： AC 220V 或DC48V
功率： 250W
纯水容量： 4 升
产品尺寸： 310×209×210 mm（长×宽×高）
主机净重： 8 Kg，含水重： 12Kg
成雾量: ≥5500ml/h
雾化粒径： 1-10微米
| |
Huifen 7805 Cleanroom Fogger |
| FOG
Duration |
about 50 minutes |
| FOG
Volume Output |
0.25 cubic meters / minute,
constant output |
| Total
FOG Volume |
about 12.5 cubic meters, pure
fog, during 50 minute cycle |
| Fog
Density (ml/minute) supports visible fog distance |
57 mL per minute converted to
pure fog |
| Visible
Fog Distance |
7-8 feet visible airflow
distance |
| FOG Type |
Ultrasonic Fog using DI Water or
WFI Water |
| Class of
Clean Room Use |
Class 1 to 10,000 |
| Compatible
Guidelines |
USP 797 Insitu Airflow Analysis,
ISO 14644-3 Annex B7, Federal Standards 209E in Semiconductor Cleanrooms |
| Type of
Room |
Clean Rooms, Sterile Rooms, ISO
Suites, Medical Rooms |
| Water
volume |
4 liters |
| Useable
Water Volume |
3.5 Liters |
| Method
of Operation |
Direct Switch Control, Cable
Remote Control |
| Method
of Movement |
Hand Carry Enclosure |
| Liquid
Weight |
3.75 Kg Water |
| Standard
Power Requirements |
110-250VAC, 50/60 Hz, 10A |
| Dimensions,
Inches |
10" H x 9" W x
11" D |
| Dimensions,
Metric |
254 mm H x 227 mm W x 280 mm D |
| Full
Weight |
8KG (including DI Water) |
